MONOCULAR MICROSCOPE on Sale

Osmium Solutions introducing LABOMED  Monocular Microscope consists of 2 Models:

A) CXL HL ;  B) CXL LED

A) MODEL CXL - LED

Code: FADCXL004LED

With top of the line features of a Student Microscope.

High Grade Achromatic Objectives & WF Eyepiece Par-centered & Parfocal on CNC Machines.

With 1W white LED on proper Heat Sink Life more than 50,000 Hours & Back-up Battery for use where Power Supply failure. easily replaceable Chargeable Cells with long life.

All moving parts on Ball Bearing Guides to give highly sensitive & smooth working.

B) MODEL CXL - HL

With 6v-20w Halogen Lamp

Code: FADCXL004HL

Technical Specification

LABOMED MONOCULAR MICROSCOPE

MODEL CXL

Stand: Sturdy stand anti rust materials. Extended base

Viewing Bodies: Monocular tube 45° inclined, 360° rotatable

Eyepieces: Wide eld eyepiece WF10x/18mm, with foldable eye guard, anti-fungus coating - locked

in ocular tube

Nosepiece: Quadruple nosepiece (Ball bearing type).

Objectives: DIN Semi-Plan Achromatic objectives 10x, 40x (spring loaded), 100x Oil (spring loaded)

anti-fungus coating. PAR-CENTERED & PARFOCAL

Mechanical Stage: Mechanical stage with Co-axial drive, highly smooth on ball slides, stainless steel

holder for slide movement X-Y = 75mm x 50mm

Focusing: Co-axial coarse and ne focusing on ball drive system for smooth movement with Tension

adjustable control knob.

Electrical: Input 200v-240v AC through external power adapter for battery charging. Lithium - Ion rechargeable battery built-in.

Illumination system:

FADCXL004LED: LED illumination, variable intensity control with illuminated ON/OFF switch, rechargeable battery. Up to 100,000 hours of LED life.

FADCXL004HL: Halogen 6V-20W illumination with variable illumination control. Up to 2,000 hours of Halogen lamp life. Illuminated ON/OFF Switch.

PACKED in styrofoam box, with operation manual, dust cover, cleaning cloth, power cord.

The objectives are high grade IMPORTED Achromats - Semi - Plan, very well CENTRED & PARAFOCAL, a feature not found in other Indian make microscopes. All the features such as mechanical stage, coaxial coarse & fine focusing mechanism, Illumination system & Sub-stage Condenser on Rack & Pinion offered in these models are the same as in other LABOMED Microscopes; hence these offer excellent performance at lowest Price.
