Phase Contrast Microscope

Osmium Solutions introducing Phase Contrast Microscope MODEL Lx400PH:

Code: FAD9126000PH For Halogen Illumination

Code: FAD9126000LEDPH For LED Illumination

Top of the line features of an Research Microscope.

With Binocular OR Trinocular 30° Inclined Head. (Viewing Height Adjustable to suit Individual user).

High Grade Phase Plan Achromatic Objectives & WF Eyepiece. Par-centered & Parfocal on CNC Machines.

Phase contrast kit compressing of phase telescope, phase turret, green & blue filters.

All moving parts on Ball Bearing Guides to give highly sensitive & smooth working.

Technical Specification

LABOMED BINOCULAR OR TRINOCULAR MICROSCOPE

MODEL Lx400 PH

Stand: Single mould Sturdy stand with anti rust materials. Extended base with hand rests for enhanced stability and comfort.

Viewing Bodies: Siedentopf Binocular OR Trinocular tube 30° inclined, 360° rotatable, Interpipullary distance adjustable 48-75mm. Vacuum coated Prism for better transmission and anti fungus character.

(Viewing Height Adjustable to suit Individual user)

Eyepieces: Wide Field focusable paired eyepiece WF10x/22mm, with foldable eye guard, antifungus coating. graduated ring for setting of individual Eye Diopter.

Nosepiece: Reverse angle Quadruple nosepiece (Ball bearing type) with click stops and rubber grip, anti-gungus coating. PAR-CENTERED & PARFOCAL on CNC Machines.

Objectives: RP series DIN Innity Corrected Plan Achromatic objectives 4x, 10x, 40x (spring loaded), 100x Oil (spring loaded) anti-fungus coating.

Mechanical Stage: RACKLESS X-axis, double plate mechanical stage size 200 x 160mm X/Y travel range 78 x 54mm. Low drive movement controls. Hard coated surface for scratch resistance. Slide holder to accommodate up-to two slides.

Condenser: Sub-stage abbe condenser NA 1.25 with aspheric lens and Iris diaphragm. Rack and pinion movements on stainless steel guides. Day light blue filter provided.

Focusing: Co-axial coarse and one focusing on ball drive system for extremely smooth operation.

Illumination: LED illumination with variable illumination control. Rechargeable Lithium Ion Battery

Provide long Hours of Battery Backup incase of electricity failure.

OR

Illumination: Halogen 6V-20W illumination with variable illumination control.

Electrical: For LED Input 180v-250v AC or for HL Input 220v-240v AC, with removable imported cord.

PACKED in Styrofoam box, with operation manual, dust cover, cleaning cloth, power cord.
